KVC (UK) factory was established in 1989; Located in Glasgow, Scotland, it is one of the subsidiaries of the Federal International Group; Specializing in researching, designing, and manufacturing various types of valves: ball valves, gate valves, globe valves, butterfly valves, etc. KVC valves are mainly provided for applications in the petroleum and natural gas industry, petrochemical industry, offshore or onshore, and seabed. KVC's quality control system has obtained Lloyds certification and complies with BS: EN ISO 9001 standard. KVC valves have also been proven to comply with BS 10204 3.1. B standards through comprehensive chemical composition testing and mechanical performance testing.
Ball ValveSize: 1/2 "-36"
Pressure level: ANSI CL150LB - 2500LB
Connection form: RF/RTJ/NPT/SW/BW/Grayloc Hub/can be customized according to special requirements
Design method: fixed ball/floating ball/full diameter/reduced diameter
Materials: Various materials ranging from carbon steel to duplex stainless steel
Design standards: BS 10204 3.1.B, API 6D, API 6FA, API 607, API STD. 598, BS2080, BS4504, BS5351, BS6755, NACE MR01-75
Gate ValveSize: 1/4 "-30"
Pressure level: ANSI CL150LB - 1500LB
Connection form: RF/RTJ/NPT/SW/BW/can be customized according to special requirements
Materials: Various materials ranging from carbon steel to duplex stainless steel
Design standards: API 600 & API STD. 598
Cut-off ValveSize: 1/4 "-12"
Pressure level: ANSI CL150LB - 1500LB
Connection form: RF/RTJ/NPT/SW/BW/and can be customized according to special requirements
Materials: Various materials ranging from carbon steel to duplex stainless steel
Design standards: API 600, API STD 598 & BS1873
Check ValveSize: 1/4 "-24"
Pressure level: ANSI CL150LB - 1500LB
Connection form: RF/RTJ/NPT/SW/BW/can be customized according to special requirements
Materials: Various materials ranging from carbon steel to duplex stainless steel
Design standards: API600, API STD598, API STD6D & BS1868
Butterfly ValveSize: 1 "-128"
Pressure level: ANSI CL125LB-150LB (also in DIN/JIS STD)
Connection form: Wafer/Lugged/Double Flanged/customizable according to special requirements
Materials: Grey iron A126 Class B, ductile iron A536 Gr.65-45-12, carbon steel A216 WCB, stainless steel A351 CF8/CF8M, aluminum copper B148
Design standards: API 609-1A, API 609-2C, BS5155 Series 13 or AWWA504 (short), ISO5752 Series 13, MSS SP-67
